Deye SUN-6K-G06P3-EU-BM2-P1 | three-phase grid inverter | 6 kW

Deye SUN-6K-G06P3-EU-BM2-P1 – 6 kW three-phase photovoltaic inverter

Deye SUN-6K-G06P3-EU-BM2-P1 is a modern three-phase inverter designed for photovoltaic installations in homes and small businesses. With an output power of 6 kW, efficiency of 98.2%, and advanced protection systems, it ensures efficient and safe PV system operation.

Main Features:

• 6 kW output power – optimal choice for medium-sized PV installations.

• 2 independent MPPT (2 × 20 A) – high flexibility when designing systems with panels at different orientations.

• Wide MPPT voltage range (120–1000 V) – stable operation under various sunlight conditions.

• High efficiency: 98.2% (euro 97.6%) – maximum energy utilization.

• IP65 enclosure – weather-resistant, suitable for outdoor installation.

• Comprehensive protection package – protection against surges (DC/AC, type II), short circuits, overload, reverse polarity, and leakage currents.

• Natural cooling – quiet operation and greater reliability.

• Communication and monitoring – optional WiFi, LAN, 4G, RS485/RS232 modules allow remote system control.

• Zero export and VSG (Virtual Synchronous Generator) functions – grid compliance and improved system stability.

Why choose Deye SUN-6K-G06P3-EU-BM2-P1?

This inverter combines high efficiency, reliability, and ease of use. With dual MPPT, it achieves higher energy production even in installations with partial shading or panels at different tilt angles. Its solid design, modern features, and compliance with European standards make it the right choice for demanding users.

Technical Specifications (selected parameters):

• AC output power: 6 kW

• Max. PV input power: 9 kW

• Number of MPPT: 2

• MPPT voltage range: 120–1000 V

• Start-up voltage: 600 V

• Max. input current: 2 × 20 A

• Maximum efficiency: 98.2%

• European efficiency: 97.6%

• Operating temperature range: -25°C to +60°C

• Protection rating: IP65

• Dimensions: 283 × 525 × 178 mm

✅ Deye SUN-6K-G06P3-EU-BM2-P1 is the ideal choice for those who expect reliability, safety, and maximum performance in medium-sized PV installations.
