Solis S6-EH1P5K-L-PLUS | Hybrid Inverter | 5 kW | 1-phase | LV

Solis S6-EH1P5K-L-PLUS Hybrid Inverter

Solis S6-EH1P5K-L-PLUS – an advanced solution for demanding power scenarios. This model is an excellent choice for homeowners who want to maximize the benefits of photovoltaics, delivering unmatched performance and versatility. With a rated output power of 5 kW and a maximum apparent power of 5 kVA on the grid side, as well as 5 kW in backup mode, it becomes the powerful heart of your energy system. The device is designed to handle high-power PV panels, offering an MPPT input current of up to 16 A, allowing flexible and efficient PV system configuration. Moreover, it supports a DC:AC ratio of 1.6.

The Solis S6-EH1P5K-L-PLUS is synonymous with smart energy management, providing precise control over your consumption. Thanks to its six-stage time-of-use (TOU) charging and discharging function and integrated artificial intelligence, the inverter optimizes energy flow based on the most favorable tariffs. Its capability to seamlessly integrate with VPP and EMS platforms results in even better energy consumption optimization, enabling active participation in grid management. A maximum battery charge and discharge current of 112 A ensures fast and efficient energy storage and delivery. This model is compatible with a wide range of popular lithium and lead-acid batteries with a voltage range of 40-60 V, giving you flexibility in choosing your system components.

In emergency situations, the Solis S6-EH1P5K-L-PLUS guarantees uninterrupted UPS-level power supply, with a switchover time of less than 4 ms, meaning your critical loads will always stay active. An independent generator interface further enhances energy security by extending backup time during prolonged grid outages. The system also offers an impressive overload capacity – 200% of nominal power for 10 seconds, which is crucial for handling equipment with high starting currents. The inverter is also ready for parallel operation with other units, allowing you to build a powerful single-phase or three-phase system with a total capacity of up to 48 kW, making it an ideal solution for future expansion.

Safety and durability are a priority in the Solis S6-EH1P5K-L-PLUS. An integrated (optional) AFCI function actively detects electrical arcs in the PV installation, minimizing the risk of fire. IP66 protection class and a wide operating temperature range from -40°C to +60°C ensure reliability in all conditions. Operation is extremely simple thanks to the 7-inch LCD screen and mobile app support via Bluetooth, enabling quick and easy configuration. Choose the Solis S6-EH1P5K-L-PLUS and gain a comprehensive, efficient, and reliable power source for your home.
