Solis S6-EH3P12K02-NV-YD-L Hybrid Inverter – The Performance Champion for Demanding Home Systems

Are you looking for a solution that will provide your home with top-level energy independence? Solis S6-EH3P12K02-NV-YD-L is a three-phase low-voltage hybrid inverter, perfectly suited for the largest residential photovoltaic installations. This advanced device not only stores green energy but also manages it intelligently, guiding your household towards zero fossil fuel energy demand.

Exceptional Energy Management

This inverter was designed with full control over your energy consumption in mind. It offers built-in control for SG-ready heat pumps and seamless integration with VPP and EMS platforms, allowing maximum energy optimization. The artificial intelligence feature, which manages battery charging and discharging based on Time-of-Use (TOU) tariffs, ensures smart energy usage and significant savings.

Uncompromising Reliability and Stability

The rated output power of 12 kW and maximum apparent output power of 12 kVA make the Solis S6-EH3P12K02-NV-YD-L ideal for the most demanding applications. The inverter provides uninterrupted operation thanks to an ultra-fast switching time of less than 10 ms, enabling smooth transition to backup power in UPS mode. It also features an impressive capacity to handle 200% overload for 10 seconds, demonstrating exceptional durability and stability. Robust protections, including anti-islanding, overload, short circuit, DC and AC surge protection, and DC reverse current protection, guarantee the highest level of safety.

The Power of Next-Generation PV Panels

Solis S6-EH3P12K02-NV-YD-L is fully compatible with high-power photovoltaic panels, supporting a maximum input current of 40A. By accepting 160% of the PV input power relative to the inverter’s rated power, it maximizes solar energy production. Outstanding maximum efficiency of 97.6% and nearly perfect MPPT efficiency of 99.9% ensure that every unit of generated energy is effectively utilized. The inverter has 2 MPPT trackers and supports 4 input strings.

Maximum Flexibility and Scalability

The inverter is compatible with both lithium and lead-acid batteries, offering an impressive maximum battery charge/discharge current of 250 A, allowing fast charging and efficient use of stored energy. The system supports three-phase unbalanced output, delivering up to 50% of the inverter’s rated power per single phase. Additionally, parallel connection technology allows up to six units of the same model to be combined into one coherent and powerful microgrid, providing enormous expansion possibilities. Integration with generators and existing PV installations (AC-coupled) offers unmatched versatility.

Simple and Convenient Operation

The intuitive 7-inch LCD screen and Bluetooth app support make configuration and monitoring extremely easy. The device’s compact dimensions of 430 × 660 × 305 mm and weight of 42 kg allow quiet operation below 65 dB(A), and it is designed to operate under harsh conditions with a temperature range from -40℃ to +60℃ and an IP66 protection rating.

At energoshop.eu, we offer the Solis S6-EH3P12K02-NV-YD-L inverter, synonymous with reliability and high performance. Invest wisely in your energy future!
