Solis S6-EH3P30K-H Hybrid Inverter | 30kW | 3-phase | HV

Solis S6-EH3P30K-H: Three-Phase Hybrid Inverter

Introducing the Solis S6-EH3P30K-H – an advanced three-phase hybrid inverter designed to optimize commercial photovoltaic systems with energy storage. This innovative product is not just a device, but a comprehensive solution that will provide your company with reliable power supply, significant savings, and full control over energy flow.

Why is the Solis S6-EH3P30K-H a worthwhile investment? By choosing this inverter, you are investing in your company’s future. The Solis S6-EH3P30K-H guarantees energy security and lower operating costs. It’s the ideal solution for large enterprises as well as smaller businesses striving for energy independence and sustainable development.

Key features and benefits that will transform your business:

• Unmatched performance: The Solis S6-EH3P30K-H inverter features an impressive MPPT efficiency of 99.9%, ensuring maximum solar energy harvesting. The overall inverter efficiency reaches 97.8%, with battery charge/discharge to AC efficiency of 97.5%. With three independent maximum power point trackers (MPPTs) and the capability to handle 200% PV input power, you maximize your solar usage.

• Smart energy management: Optimize costs thanks to smart charge and discharge management based on Time of Use (TOU) tariffs. The inverter is also ready to integrate with Virtual Power Plants (VPP) and frequency service providers, opening new revenue opportunities.

• Reliable backup power: In the event of a grid failure, the Solis S6-EH3P30K-H provides UPS-level switching in under 10 ms. This means your company’s critical loads (e.g., air conditioners, pumps) keep running seamlessly, even with up to 160% overload in off-grid mode (for 2 seconds). The device also supports 100% unbalanced three-phase output and half-wave loads, ensuring stability in every scenario.

• Exceptional flexibility and scalability: The inverter is compatible with a wide range of high-voltage lithium batteries, offering a voltage range from 150 to 800 V and a maximum charge/discharge current of 140 A (70 A x 2). With the option to connect up to 6 units in parallel, the system can be easily scaled to meet your company’s growing energy needs. Additionally, it supports an independent generator port with automatic On/Off control.

• Easy installation and intuitive operation: The inverter is designed for user convenience. A 7-inch LCD screen and Bluetooth app support make configuration quick and easy. System monitoring is convenient and possible remotely via the SolisCloud platform. Compact dimensions (530 x 880 x 290 mm) and a relatively low weight (73 kg) make installation easier.

• Comprehensive protection: Safety is a top priority. The Solis S6-EH3P30K-H is equipped with an integrated AFCI function (arc fault detection) and numerous protective mechanisms such as anti-islanding, output overcurrent, short circuit, DC reverse polarity, and type II surge protectors for both DC and AC. The IP66 protection rating ensures resistance to external factors.

Key Technical Data (model S6-EH3P30K-H):

• Rated power: 30 kW
• Max. PV input power: 60 kW
• Number of MPPTs: 3
• Battery voltage range: 150 - 800 V
• Max. charge/discharge current: 70 A x 2
• Backup switchover time: <10 ms
• Dimensions (W × H × D): 530 × 880 × 290 mm
• Protection rating: IP66
• Operating temperature range: -25°C to +60°C

Invest in smart energy for your business! The Solis S6-EH3P30K-H is not just an inverter — it’s a step towards true energy independence and efficiency. Add it to your cart today and see what it can do for you!
